Bottom Fill Gravimetric Electronic Automatic eXplosion-Proof Liquid Filling Machines

The ABA-FILL-BF Bottom Fill Series are designed to fill below the level of the liquid to minimize foaming and protect against exposure to static prone products. Submerging the fill nozzle beneath the product as it is filling prevents air in the product, and helps to eliminate foaming and static buildup. This in turn allows the products to be filled more quickly and in a safer manner.

On our bottom fill machines, the diving lance style fill head is lowered into the bottom of the container utilizing either a Servo motor or a pneumatic air cylinder. Both methods offer accurate and easily adjustable filling and tracking. Once the fill cycle starts, the fill carraige slowly rises, drawing the fill head(s) up as it goes. As the container is filled with liquid, the head of the fill lance remains submerged under the level of the liquid. These net weight filling machines are highly accurate and will increase the efficiency of any plant.

Features:

• Fills restricted opening containers (screw caps) as well as open top containers

• High accuracy

• Fills half pint, pint, quart, and gallon cans as well as 5 gallon pails

• Electronic controls

• Fully automatic

• One to six fill stations

• Explosion proof for C1D1 or C1D2 area
